Magnification

4 x – 20 x

Effective lens diameter

49 mm – 58 mm (1.93 " – 2.28 ")

Exit pupil diameter

12.3 mm – 2.9 mm (0.48 " – 0.11 ")

Field of view at 100 m (109 yds)

9.2 m – 1.9 m (10.0 yds – 2.0 yds)

Eye relief

90 mm (3.5 ")

Transmission

> 90% night

Parallax compensation

50 m (54.7 yds) to infinity,100 m (109 yds) arresting

Elevation adjustment at 100 m (109 yds)

±75 cm (0.82 yds)

Elevation adjustment with QDC at 100 m

80 cm (31.5 ")*

Windage adjustment at 100 m (109 yds)

±50 cm (19.68 ")

Adjustment per click

1 cm / 100 m (0.39 " / 109 yds)

Weight

770 g (31.22 oz)

Overall length

365 mm (14.37 ")

Objective bell outside diameter

64,5 mm (2.5 ")

Eyepiece outside diameter

45 mm (1.77 ")
